Ixsu-F/Oxsu-F Ceramic Semiconductor Stress Control Cable Accessories
- CCMT
- CHANGCHUN,CHINA
- Based on the order quantity
- 10,000 units per month
1.We adopt the use of a ZnO ceramic stress control technology to improve electrical field distribution, and at the same time increase operational safety, for the cables subjected to a high voltage.
2. The heat shrink terminators rely on a high-quality heat shrink insulation material which gives the termination excellent insulation, in addition to being a great waterproof and weatherproof material.
3. One of our cable termination kits is of the heat shrinkable type, it has a simple structural design for quick installation, mechanical strength not affected, and adaptability to an environment still good.
Due to different structure in cable terminations and joints, electric field concentration will be easily generated when the medium and high voltage cables in service. These kinds of electric field disturbances may give rise to partial discharge, degradation of insulation material, and equipment breakdown. The difficulty of implementing conventional stress control solutions is that they do not have good stability and at the same time provide good sealing if you are operating the cables outdoors for a prolonged period of time or working in a complex environment.
Our Professional Solution:
Cable heat shrink tubing is a new and innovative cable termination and joint solution specially designed for 15kV to 35kV medium and high voltage power systems. The major advantage is that it uses state-of-the-art ZnO zinc oxide stress control technology which allows for the electric field homogenization via ceramic semiconductor materials. In this way, it significantly mitigates the electric field concentration around cable insulation cut areas.
When it is combined with heat shrinkable insulation tubing and high-performance polymer materials, a reliable sealing structure is made. This structure is able to conform to the irregularities of the cable surface and create a stable connection with the insulation layer to give excellent insulation, moisture sealing, and assure the cable system will work properly for a long time.
Product Parameters:
Parameter | Unit | 8.7/15 kV | 26/35 kV |
Voltage Level | kV | 8.7/15 | 26/35 |
Applicable Cable Diameter Range | mm | 16~47 | 28~60 |
Applicable Cable Cross-section Range | mm² | 25~800 | 35~800 |
Applicable Number of Cores | - | 1-core or 3-core | 1-core or 3-core |
Maximum Equipment Voltage (Um) | kV | 17.5 | 40.5 |
Impulse Withstand Voltage | kV | 95 | 200 |
Partial Discharge at 2U₀ | pC | < 5 at 18kV | < 5 at 52kV |
AC Withstand Test Voltage (5 min) | kV | 39 | 117 |
Product Advantages:
1. Excellent Electric Field Stress Control Capability.
The heat shrink terminations are based on the use of a varistor ceramic stress control system made from ZnO-based ceramic. It works well to decrease the electric field at locations where the electric field is concentrated by the use of such varistor ceramic materials, which allows for varying of the electric field distribution. When a partial discharge is tested under a 2U₀ test voltage, the partial discharge is less than 5 pC which leads to a lower probability of partial discharge and thereby, it improves the reliability of medium and high voltage cable terminations and joints.
Moreover, the product can withstand both 95 kV and 200 kV of lightning impulse withstand voltage so that the safety margins can be assured even in extreme conditions of overvoltage.
2. High-Performance Insulation and Sealing Protection.
The heat shrinkable cable termination kit consists of an optimized polyolefin and rubber-plastic alloy copolymer material. Following radiation cross-linking treatment, this material is extremely insulated and weather-resistant. The AC withstand voltage test of this material for 5 minutes can be either 39kV for (8.7/15kV) and 117kV (26/35kV), confirming that it has a reliable insulation system and it also is resistant to moisture, pollution, and changes in the external environment.
3. Easy Installation, Improving Construction Efficiency.
A heat-shrinkable outdoor termination set includes a compact layout composed of only few parts. The termination kit can accommodate 1-core and 3-core cables as well as cable diameter ranges of 16-47 mm and 28-60 mm respectively. An array of advantages such as great flexibility, a hassle-free method of fitting, and only minimum tools, which altogether make it less demanding for the worker and more efficient at the worksite.
4. Mechanical Performance and Environmental Resistance.
This line of products has exceptional mechanical strength besides being highly resistant to scratches, corrosion, and bad weather. The maximum apparatus voltage (Um) varies between 17.5 kV and 40.5 kV, making it fit for different application scenarios like outdoor operation, high humidity, and diverse climatic conditions, which in turn guarantee stable and reliable performance for an extended period.
Product Application Scenarios:
· Used in the Transfer and Distribution of Electricity: Can be used to reinforce cable systems' operation safety in cities, factories, and during the building of power infrastructure.
· New Energy: Used in wind power generation, solar power generation, and energy storage power stations.
· Industrial Facilities: Suitable for industrial power supply systems with high requirements for cable safety and continuous operation capability, such as petrochemical plants, mines, manufacturing plants, and high-energy-consuming enterprises.
· High-Reliability Application Areas: nuclear energy, aerospace and special engineering projects, and special industrial scenarios with strict requirements for equipment reliability, stability and service life.
CCMT's Corporate Strength:
Since the company's inception in 1986, our firm has capitalized on over 40 years of industry expertise to construct a mature product development framework and maintain steady manufacturing, continuously supplying customers worldwide across the power, energy, and industrial sectors. In its course of development that took many years, the company has steadily grown and now operates a modern manufacturing site measuring over 10,000 sq. m, employing a staff of over 200 professionals; as a result, it has become a large manufacturing enterprise.
Alongside that, our company boasts more than 40 production lines in total. Specifically, these consist of 13 plastic extrusion production lines, 10 oil expansion production lines, along with two special purpose ones for the production of heat-shrinkable cables (heat-shrinkable cable terminals/connectors). We currently can fabricate over 10,000 sets of heat-shrinkable cable terminals/connectors per month.
International Quality System Certification, Meeting Global Market Requirements:
We have established an ISO 9001:2015 quality management system (No. 00123Q36311R5M/2200), strictly implementing standardized production and quality management processes. Furthermore, our products have obtained relevant certifications such as CE, SGS, and IEC, and comply with international environmental regulations such as RoHS and REACH, meeting the market access requirements of different countries.
Global Market Application Experience, Gaining International Customer Recognition:
Our cable accessories have been exported to countries and regions including Saudi Arabia, Turkey, the UAE, India, the Philippines, Thailand, Brazil, and Argentina. We have also supplied ultra-thick three-layer co-extruded heat-shrinkable composite tubing to RAYCHEM, customized insulating tape to 3M, and low-voltage heat-shrinkable tubing to ABB.
Participation in International Exhibitions, Continuously Expanding Our Global Cooperation Network:
We reveal to foreign buyers our capacity to manufacture products, our technological advancements, and our quality system by participating in international exhibition platforms. This is an effective platform through which we can better acquaint ourselves with international market conditions and at the same time get in communication with overseas customers, industrial companies, and business partners, thereby creating a strong basis for the testing of products, collaborative work, and the manufacture of goods in volume.
